AYN Odin Handheld Review: Specs, Performance, and Buying Guide

AYN Odin Handheld Review: Specs, Performance, and Buying Guide

Overview

The AYN Odin is a high-performance Android handheld gaming device that combines a familiar 16:9 aspect ratio with powerful internals. Powered by the Qualcomm Snapdragon 845 processor and Adreno 630 GPU, it delivers smooth performance for Android games and emulation up to some PlayStation 2 titles. The device features a 5.98-inch IPS touchscreen with 1920x1080 resolution, active cooling with a fan, and a large 6600 mAh battery for extended play sessions.

Key Specs Highlights

  • Processor: Snapdragon 845 (8 cores, up to 2.8 GHz)
  • GPU: Adreno 630 (787 MHz overclocked)
  • RAM & Storage: 4GB/8GB LPDDR4x RAM, 64GB/128GB UFS 2.1 storage + MicroSD
  • Display: 5.98-inch IPS, 1920x1080, 60Hz, ~368 PPI
  • Battery: 6600 mAh
  • Connectivity: WiFi 5, Bluetooth 5.0, USB-C video output, Micro HDMI, 3.5mm headphone jack
  • Weight: 368 grams
  • OS: Android

Who It Is For

The Odin is ideal for retro gaming enthusiasts who want to emulate consoles up to the PlayStation 2 era, as well as Android gamers looking for a dedicated device with physical controls. It's also suitable for those who prefer a 16:9 screen for streaming or cloud gaming. The active cooling and Hall effect joysticks make it a solid choice for longer gaming sessions.

Buying Notes

Available in multiple colors (black, white, purple transparent, white transparent), the Odin comes in Base and Pro variants. The Base model (4GB RAM, 64GB storage) launched on Indiegogo at $199-$225, retailing at $243. The Pro model (8GB RAM, 128GB storage) was $239-$275 on IGG and $293 retail. Prices may vary by seller and region. Note that the device supports up to some PS2 games but not all; performance depends on the emulator and game settings.

Specifications
CPUCortex-A75 / Cortex-A55
GPUQualcomm Adreno 630
内存4 GB LPDDR4x (Base) / 8 GB LPDDR4x (Pro)
别名Odin, Odin 1, AYN Odin, Odin 1st Gen
名称Odin
品牌AYN
存储Internal 64 GB UFS 2.1, 128 GB (Pro), External MicroSD
振动Yes
散热Cooling fan and vents
电池6600 mAh
重量368 grams
CPU主频1.7 GHz - 2.8 GHz
处理器Qualcomm Snapdragon 845
屏幕PPI368.38
扬声器Dual stereo speakers
连接性WiFi 5, Bluetooth 5.0
价格区间$200 - $300
发布时间January 2022
外壳材质Plastic
外观尺寸224 mm x 95.2 mm x 15 - 23.7 mm
屏幕尺寸5.98 inches
屏幕比例16:9
屏幕类型IPS touchscreen
握持类型Horizontal
操作系统Android
机身颜色Black, White, Purple Transparent, White Transparent
视频输出USB-C video output, Micro HDMI
起售价格$199 - $225 (Base IGG), $243 (Base Retail), $239 - $275 (Pro IGG), $293 (Pro Retail)
音频输出3.5mm headphone jack
GPU核心频率787 MHz (OC)
其他传感器Gyroscope, microphone, Hall effect joysticks
屏幕分辨率1920 x 1080
屏幕刷新率60Hz
CPU核心和线程数8 cores, 8 threads
模拟器游戏支持Up to some PS2 games

Full specs and updates on our site: https://www.oldman.dpdns.org/en/handheld/odin
